QX-5 Twenty

ש"ח QX-5 Twenty USB2 – 58,080

ש"ח QX-5 Twenty NET2 – 60,720

ש"ח QX-5 Twenty Full2 – 66,000

מידע נוסף

מותג

Ayre

QX-5_FRONT
QX-5_DIGITAL_CATEGORY
QX-5_BACK
QX-5_FRONT
QX-5_DIGITAL_CATEGORY
QX-5_BACK
Full Screen

In today’s digitally-connected world you need more than just a DAC or a streamer. You need a device that can effortlessly render your highest resolution files and, without missing a beat, play your favorite music streaming services or BBC broadcast. Featuring the new ESS ES9038PRO DAC chip and a new jointly-developed doubly-rotated Morion quartz crystal-based oscillator, The QX-5 Twenty elevates digital performance to an astonishing level. Linking all of your digital media together with every conceivable digital input and the most popular music streaming services, the QX-5 Twenty streaming DAC provides unlimited flexibility and convenience at the highest level.

Features

zero-feedback and fully-balanced discrete circuitry

Ayre’s Asynchronous S/PDIF input

ESS ES9038PRO DAC chip

Ayre & Morion jointly-developed crystal oscillator

Ayre’s Minimum Phase digital filter

Single-pass 16x oversampling

Ayre’s Diamond output stage

Ayre’s exclusive Equilock circuit

100 step digital volume control

Linear analog power supply

High-speed circuit board material

Ten digital inputs: Ethernet, Asychronous USB, AES/EBU (2), Optical (3), S/PDIF (3)

Ayre Conditioner power line RFI filter

AyreLink communication system

Specifications

Audio Inputs

USB: 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz

PCM 16, 20, 24 bits

DSD64 and DSD128 (as DoP)

USB2: 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384, 768 kHz

PCM 16, 20, 24 bits

DSD64, DSD128, DSD256, DSD512

Optical/SPDIF/AESEBU: 44.1, 48, 88.2, 96, 176.4, 192 kHz

PCM 16, 20, 24 bits

DSD64 (as DoP)

Network: 44.1, 48, 88.2, 96, 176.4, 192 kHz

PCM 16, 20, 24 bits

DSD64 (as DoP)

NET2: 44.1, 48, 88.2, 96, 176.4, 192 , 384 kHz

PCM 16, 20, 24 bits

DSD64, 128, 256

Outputs

Line Output: 4.5 Vrms balanced, 2.25 Vrms single-ended

Headphone Output: 9.0 Vrms balanced, 4.5 Vrms single-ended

XLR Input Polarity

Pin 1 = Ground

Pin 2 = Non-inverting (Positive)

Pin 3 = Inverting (Negative)

Power Consumption

60 watts in operating mode

Dimensions

17.25″ W x 13.00″ D x 3.75″ H

(44cm x 33cm x 10cm)

Weight

16 pounds (7.25 kg

מידות

52,800.00
